Aluminium High Speed Doors HSD05-NF

mo-ta-sp-HSD05-NF
Model:
HSD05 - NF
Area of ​​use:
Used as the main door, installed right in the entry and exit area, where there is a high traffic density.
Opening / losing speed:
0.6 - 1.5 (m/s)
Lead time:
15 - 20 days
Delivery method:
Road transport

Aluminum High Speed Doors HSD05-NF are manufactured on demand with European quality standards, considered as a solution to support flexible circulation, and wind resistance, and prevent dust and insects at logistics warehouses, and manufacturing plants…

High speed door HSD05-NF is a rolling door type with aluminum shaped body. The product is capable of fast opening and closing with roller technology, preventing heat loss, preventing insects, dust, and wind resistance… The door is designed in a modern, luxurious way with roller rolling technology, the door body is made of aluminum alloy sheets to form a sturdy curtain that has the ability to quickly open and close with the roller rolling technology, preventing heat loss and good wind resistance.

The door is mainly installed outside the warehouse or the main door area where there is a relatively high traffic density and needs security control, insects…

ADVANTAGES

  • Fast opening/closing speed: From min 0.6 – max 1.5 m / s to help save time, and cost, minimize heat loss and prevent potential risks such as dirt, insects, and food safety…
  • Stable operation: The door frame is made of galvanized steel, which prevents the door from shaking at the highest opening and closing speed.
  • Good wind resistance: Wind resistance, security, heat loss prevention, and insect and dust intrusion, help the vehicle move back and forth easily. (Open / close automatically depending on the suitable opening/closing device selection).
  • Health safety: Curtain material does not contain DOP harmful to health, resists UV radiation, and can be used in environments of -15 to +50 degrees Celsius.
  • Safety assurance: Emergency notification system when there is a problem, easy to open by hand if there is a power outage or technical error.
  • Easy to use and clean: Diverse and simple control system, curtains are easy to clean.
  • Meet food safety standards: Produced according to European technology standards. Helping the factory to meet the safety standards in production operations: ISO 14000, ISO 45001: 2018, ROHS, HACCP, GMP…
  • Reduce costs when increasing productivity.
  • Modern design, ensure aesthetics.
Condition: New
Brand name: Naviflex
Place of origin: Vietnam
Size: 6000×6000 (mm) / On request
Open/close cycles: 300 (times / day)
Material: Shaped aluminum
Door plate thickness: 9.5 (mm)
Color: Ice cream (standard) / Optional
Technology: Powder coating ASTM standard
Temperature range: 10˚C (No freezing)
Voltage: 1 phase 220 ± 10% V, 50 / 60HZ
Wattage: Based on door area and usage environment
Safe device: Cable break device & Obstacle sensor
Control: Options based on frequency, area opening and closing areas, environmental conditions.
Warranty: 1 years
Structure:
Installation location:

ACCESSORIES

Control box

motor-va-bo-keo-cua-bang-xich-SD01-TCMotor

Door rails

Roller shaft cover box



tu-dien-HSD05-NF

Electrical cabinets



Standard optical sensor

tru-canh-bao-HSD05-NF

Warning post

remote-HSD05-NF

Remote

Warning lights

bo-luu-nguon-HSD05-NF

Power storage

tu-bao-ve-hop-dien-HSD05-NF

Electrical box protection cabinet

cam-bien-tu-kho-lanh-HSD01-NF

Cold storage sensor

bo-cam-bien-dao-chieu-HSD05-NF

Reversing sensor

Wire jerks

Radar

the-tu-HSD01-NF

Card from

cam-bien-nen-HSD01-NF

Background sensor

INSTALLATION

bang-ve-ky-thuat-HSD05-NF

Technical drawing of aluminium high speed door HSD05-NF

H: Clearance height ≤ 6000 (mm)
W: Clearance width ≤ 6000 (mm)
kich-thuoc-lap-dat-cua-HSD05

Technical drawing of aluminium high speed door HSD05-NF

H: Clearance height ≤ 6000 (mm)
W: Clearance width ≤ 6000 (mm)
sT: Space waiting for the top of the door. min: 550 (mm)
sS: Space waiting for the door wall on the side with the motor and the electrical cabinet. min: 350 (mm)
sR: Space to wait for door wall without motor and electrical cabinet. min: 150 (mm)
Operation:

Aluminum high speed door HSD05-NF is integrated with modern control technology: radar, remote, background sensor, optical sensor, magnetic sensor, push button, interlock… according to European standards, helping the operation simple, safe suitable for many different environments.

Push button

How to operate: press the control button located on the wall to open the door (close and emergency stop). Then move the car through the door, and the door will close by itself (self-closing time can be adjusted).

van-hanh-HSD01-NF-01

Remote control

How to operate: press the button on the remote to open the door (close and emergency stop). Then move the car through the door, and the door will close by itself (the self-closing time can be adjusted).

van-hanh-HSD01-NF-03

Wire jerks

How to operate: pull the control cord located in front of the door to open the door. Then move the car through the door, and the door will close by itself (self-closing time can be adjusted).

van-hanh-HSD01-NF-04

Background sensor

How to operate: drive the forklift to the sensing area (size required) to open the door. Then move the car through the door, and the door will close by itself (the self-closing time can be adjusted).

van-hanh-HSD01-NF-05

Motion sensor

How to operate: when the car or person reaches the motion sensor area in front of the door, the door will move and open the door. Then move the car through the door, the door will close by itself (self-closing time can be adjusted).

van-hanh-HSD01-NF-06

Electromagnetic lock

How to operate: Use magnetic card or hand sensor to open the door. Then move the car through the door, the door will close by itself (self-closing time can be adjusted).

van-hanh-HSD01-NF-02

Application:
Certification:
Packaging Details:

Packing in wooden/cotton/PE film carton.
